Laboratories of MiNDaP Lab. are located at Rm. 607 Yeongu-build. and Rm. 609 of Bima build. labratories consist of experiemntal and research area for RF and microtechnology. It contains several facilities for computer aided design of 2D/3D structure, metrology and device characterization. Major pieces of equipment in MiNDaP labratories include: working space, network analyzer, impedance meter, LCR meter, vibration excitor, accelerometer, oscilloscope, oven, optical microscope.
 |
 |
 |
 |
|---|---|---|---|
| Oscilloscope & Power Amplifier | Vibration Exciter | Function Generator & Acceleration Measurement | Coil Winder |
 |
 |
 |
|
| Electrometer | Linear Motor | Force Gauge | 3D Printer |
 |
 |
 |
 |
| Probe station & Vibration Isolator | Power Amplifier & Precision Materials Analyzer & LCR Meter | Semiconductor Parameter & Analyzer | LCR Meter |
 |
 |
 |
 |
| Network Analyzer | Impedance Measurement | Function Generator & DC Power Supply | Oscilloscope |
 |
 |
 |
 |
| Wire Bonder | Screen Printer | Optical Microscope | Optical Microscope |
 |
 |
 |
 |
| Convection Oven | Solder Iron & Heat Gun | Hot Plate | |
